ÜRETİCİ KODU

YSR304W
MANUFACTURER

Shenzen Aglare Lighting Co., Ltd.
PRODUCT GROUP

LED Indication - Discrete
ORDER CODE
Sipariş kodunu panoya kopyala
LED0156X0006
PRODUCT NAME
Ürün adını panoya kopyala
LED TH Red Clear STD 2.1V 2000mcd 110mW 3 x 5.3mm Radial Aglare

Ürün Özellikleri Listesi
Product Features	Özellik İçeriği	Tümü
Manufacturer	Shenzhen Aglare Lighting Co., Ltd.	Manufacturer
Color	Red	Color
Lens Color	Clear	Lens Color
Lens Transparency	Clear	Lens Transparency
Lens Style/Size	Round with Domed Top	Lens Style/Size
Voltage - Forward (Vf) (Typ)	2.1V	Voltage - Forward (Vf) (Typ)
Current - DC Forward (If) (Max)	30mA	Current - DC Forward (If) (Max)
Millicandela Rating	2000mcd	Millicandela Rating
Current - Test	20mA	Current - Test
Power Dissipation (Max)	110mW	Power Dissipation (Max)
Wavelength - Dominant	-	Wavelength - Dominant
Wavelength - Peak	635nm	Wavelength - Peak
Viewing Angle	20°	Viewing Angle
Mounting Type	Through Hole	Mounting Type
Package / Case	Radial	Package / Case
Size / Dimension	3mm x 5.3mm	Size / Dimension
Height (Max)	5.30mm	Height (Max)
Packaging	Bulk	Packaging
Configuration	Standard	Configuration
LED Type	Domed	LED Type
